T-1000S SD Card 2048 Pixel LED controller
Product Description
controller + SD Card + Led edit Sofeware + User Manual
1.The System features
1.32-256 Gray level.Support software Gamma correction.
2.Support the rules and special-shaped handle.
3.Single-port output,can support 1024 Pixels.
4.Off-line(SD Card) control, play back content stored in the SD card.
5?T-1000S store a maximum of 16 programs?copy multiple files to the SD card in order,after formatting the SD card as "FAT" format.
6.The program must be named in orders . just as ?00_1.led, 01_1.led, 02_1.led.
7.Compatible with single line or double line chips.
NOTE:
a. When T-1000S controller control less than 512 lamps the frame
rate can reach 30fps. When T-1000S control more than 512 lamps and
less than 2048 lamps the frame rate will slow down automatically.
b. T-1000S must use the new software LedEdit 2012.
2.Support chips:Chip type:
LPD6803,D705,1101,6909,6912,LPD8806,LPD8809,TM1803,TM1804,TM1809,
TM1812,M1903,TM1904,TM1909,TM1912,UCS6909,UCS6912,UCS7009,UCS5903,
UCS1903,UCS1909,UCS1912,UCS3903,WS2801,WS2803,WS2811,DS189,TLS3001,DMX512(170/512Pixels),
TLS3002,TLS3008,P9813,SM16715,SM16716,BS0901,BS0902,BS0815
NOTE:
For the TTL(SPI) signal, the controller signal ground must connect to the LED ground directly.
Click here
T-1000S_manual.pdf to download the T-1000S user's manual.
|
|
